Quality - Model S-101 vertical mailbox has a level of quality and durability that is unequalled in our industry.

Security - Constructed with heavy gauge reinforced extruded aluminum to give a lifetime of service and maximum protection for the mail.

Performance - The trim and doors have striated vertical lines to resist scratching and marring. All exposed materials are of a fine quality aluminum; smooth interior surfaces are maintenance free.

Installation - The excellence of design allows the mailboxes to be installed easily and quickly.

Locks - All compartment doors come equipped with 5-pin cylinder C.P. approved locks with 2 keys. 1,000 changes.

Identification: Cardboard name tags supplied as standard.
(Engraved plastic numbers riveted extra charge)

• Available in single compartment or up to 7 compartments wide.

• D size doors on 2, 3, 4, 5, 6 and 7 gang groupings are optional.

Group of
1	2	3	4	5	6	7
Wall Cutout
6-1/2" (16.5cm)	12" (30.5cm)	17-1/2" (44.5cm)	23" (58.5cm)	28-1/2" (72.4cm)	34" (86.4cm)	39-1/2" (100.3cm)
Frame Size
8" (20.3cm)	13-1/2" (34.3cm)	19" (48.3cm)	24-1/2" (62.2cm)	30" (76.2cm)	35-1/2" (90.2cm)	41" (104.1cm)

Door Sizes: Standard - 5 1/2" x 16" (14cm x 40.6cm)
Double - 11" x 16" (28cm x 40.6cm)
